Keeper, HT Steel, 0.310" Stem x 7.0°, Various HD® Applications
Keeper, HT Steel, 0.310" Stem x 7.0°, Various HD® Applications
SKU:51014-4
Regular price
$17.66 USD
Regular price
$17.66 USD
Sale price
$17.66 USD
Unit price
per
Couldn't load pickup availability
Harley-Davidson® EVOLUTION™ 1984-1999 (4prs. required)
Harley-Davidson® EVO SPORTSTER™ 883cc 1986-'03 (4prs. required)
Harley-Davidson® XL™ 1100cc 1986-1987 (4prs. required)
Harley-Davidson® EVO SPORTSTER™ 1200cc 1988-'03 (4prs. required)
Harley-Davidson® TWIN CAM™ 88" 1999-2004 (4prs. required)
KPMI® manufactures keepers from high tensile strength H. T. Steel.
Close attention to details such as taper angle, bead location, ID, OD, radius dimension of bead style keepers, and width of square groove style keepers insure proper, repeatable fitment and assembly locations.
| Keeper Style | Single Square Bead |
| Quantity | Various |
| Stem Diameter "A" | 0.310" |
| Keeper Angle "B" | 7.0º |
| Bead Height "C" | 0.190” |
| Overall Length "D" | 0.380” |
| Minor Diameter "E" | 0.380” |
| Rep. HD® OEM P/N | 18229-83 |
| Note | The bead height is referenced from the minor diameter of the keeper to the center of the bead. |
| Unique Identifier No. | FR327789_01GAUS |
