Beehive Spring Kit, High Lift, 0.640" Lift, HD® M8™ (& CVO’s*) 2017-2024

Beehive Spring Kit, High Lift, 0.640" Lift, HD® M8™ (& CVO’s*) 2017-2024

SKU:20-24400

Regular price $539.84 USD
Regular price $539.84 USD Sale price $539.84 USD
Sale Sold out
Retainer Material

California Prop 65

*2023-2024 CVO’s check valve lift to determine compatibility with KPMI® spring kits

  • KPMI® designed and custom wound 0.640” lift springs manufactured by PSI
  • Lightweight Titanium or Heat Treated Steel Retainers and Beehive Springs reduce reciprocating mass while providing the spring forces required for high-lift camshaft and sustained high rpm’s
  • Ultra strong high angle 9° HT Steel keepers resist “pull thru”
  • KPMI® made OEM replacement seals, #71046-8 are included for a more complete performance valvetrain solution

By taking advantage of the latest development in valve spring wire chemistry and manufacturing techniques, KPMI® has developed ovate wire Beehive style springs that will live and Perform at a high level in Harley Davidson® applications. By coupling these developments with strict KPMI® design protocols and employing multiple design, simulation, and FEA analysis software, we were we able to overcome the torsional stresses unique to ovate wire springs that previously severely limited their operating parameters. KPMI® Beehive Springs are progressively wound using Kobe Super-Clean chrome silicon based wire that is heat treated and shot peened. The hardened steel basewashers included in these kits are designed to locate the spring and control lateral movement. KPMI® made OEM replacement seals are included for a more complete performance valvetrain solution.

Installation Instructions Click Here for Kit, 20-24350
Click Here for Kit, 20-24400
Type Intake/ Exhaust
Retainer Material Titanium or H.T. Steel
Valve Lift 0.640"
Installed Height 1.580"
Seat Pressure 83#
Open Pressure 285#
@ Lift 0.640"
Unique Identifier No. FR327789_01GAUS
